Order no.: 0142560

BR-50

Order no.: 0142560

BR-50

Bass rocker, 50 W, 4 Ω Special technology for producing a structure-borne sound Mounting to a seat or also to a floor or dance floor capable of vibrating Generates a powerful bass which can physically be felt Easy screw mounting Connection to suitable power amplifier via basic passive crossover network as for subwoofers, or even better via an individual amplifier Series or parallel connection of several BR-50 devices is possible like with common bass speakers Resonant frequency: 40 Hz (varies due to mounting to different surfaces) Frequency range: approx. 30-300 Hz Even mounting surface required of at least 110 x 110 mm Dimensions: 131 x 131 x 56 mm Weight: 1.232 kg

continue

About

Bass rocker, 50 W, 4 Ω

Special technology for producing a structure-borne sound
Mounting to a seat or also to a floor or dance floor capable of vibrating
Generates a powerful bass which can physically be felt
Easy screw mounting
Connection to suitable power amplifier via basic passive crossover network as for subwoofers, or even better via an individual amplifier
Series or parallel connection of several BR-50 devices is possible like with common bass speakers
Resonant frequency: 40 Hz (varies due to mounting to different surfaces)
Frequency range: approx. 30-300 Hz
Even mounting surface required of at least 110 x 110 mm
Dimensions: 131 x 131 x 56 mm
Weight: 1.232 kg

Specifications

Impedance (Z)	4 Ω
Frequency range	30-300 Hz
Resonant frequency (fs)	40 Hz
Power rating (RMS)	50 W
Peak music power output (MAX)	100 W
SPL	no data
Mounting cutout	not applicable
Dimensions	131 x 131 x 56 mm
Outside diameter	Ø 152 mm
Width	131 mm
Height	131 mm
Depth	56 mm
Colour	black
Admiss. ambient temp.	0-40 °C
Weight	1.232 kg
Packing unit	1
Packing dimensions (W x H x L)	0.145 x 0.07 x 0.145 m
Gross weight	1.32 kg
Net weight	1.232 kg
