Bass 2-way crossover network for 8 Ω for PA
  • Highest power rating
  • Film capacitors
  • Transformer core coil
  • Frequency and slopes typical for PA
  • Extendable
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com
continue

About

Bass 2-way crossover network for 8 Ω for PA
  • Highest power rating
  • Film capacitors
  • Transformer core coil
  • Frequency and slopes typical for PA
  • Extendable
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Germany
info@monacor.com

Specifications

General Information PA - sub/sat mono
Output impedance 8 Ω
Crossover frequency 200 Hz
Slope/oct. B: 12 dB /MH: 6 dB
Max. input power 600 W
Dimensions 140 x 60 x 135 mm
Weight 1 kg
EAN code 4007754071009
Net weight 1.002 kg
