Order no.: 0233480

ECM-250

Order no.: 0233480

ECM-250

Electret microphone set, consisting of two overhead electret microphones. Optimised for sound pickup of drum combinations and percussion instruments Short-bodied microphones Low cut switch, selectable 10 dB attenuation 48 V phantom power Including microphone holder with 16 mm (⅝") tripod socket and 9 mm (⅜") adapter screw Supplied in a practical plastic case

continue

About

Electret microphone set,

consisting of two overhead electret microphones.

Optimised for sound pickup of drum combinations and percussion instruments
Short-bodied microphones
Low cut switch, selectable 10 dB attenuation
48 V phantom power
Including microphone holder with 16 mm (⅝") tripod socket and 9 mm (⅜") adapter screw
Supplied in a practical plastic case

Specifications

Description	overhead microphone
Transmission method	cable
Polar pattern	cardioid
System	electret
Audio frequency range	50-16,000 Hz
Nominal impedance	200 Ω
Sensitivity	18/5.6 mV/Pa
S/N ratio	66 dB
Max. sound pressure	130 dB
Power supply	DC 48 V, phantom power
Admiss. ambient temp.	0-40 °C
Dimensions	Ø 19 mm x 80 mm
Weight	25 g
Connection	XLR, quasi-balanced
Packing dimensions (W x H x L)	0.16 x 0.085 x 0.275 m
Gross weight	0.515 kg
Net weight	0.145 kg
