Order no.: 0231970

JS-22

Order no.: 0231970

JS-22

Professional condenser microphone, for studio applications and live performances. Ideally suited for direct or overhead sound pickup of acoustic instruments, percussions and vocals or 2 x JS-22 for high-quality stereo recordings. 1.25 cm (½") extra thin gold-plated diaphragm Low cut switch (80 Hz) 10 dB attenuation, switchable 48 V phantom power Robust brass body of high quality Supplied accessories: robust hard-sided case, microphone windshield and microphone holder

continue

About

Professional condenser microphone,

for studio applications and live performances. Ideally suited for direct or overhead sound pickup of acoustic instruments, percussions and vocals or 2 x JS-22 for high-quality stereo recordings.

1.25 cm (½") extra thin gold-plated diaphragm
Low cut switch (80 Hz)
10 dB attenuation, switchable
48 V phantom power
Robust brass body of high quality
Supplied accessories: robust hard-sided case, microphone windshield and microphone holder

Specifications

Description	condenser microphone
Transmission method	cable
Polar pattern	cardioid
System	condenser
Audio frequency range	20-20,000 Hz
Nominal impedance	100 Ω
Sensitivity	15.8 mV/Pa
S/N ratio	78 dB
Max. sound pressure	140 dB
Power supply	DC 48 V, phantom power
Housing material	brass
Admiss. ambient temp.	0-40 °C
Dimensions	Ø 20 mm x 150 mm
Weight	130 g
Connection	XLR, bal.
Packing dimensions (W x H x L)	0.172 x 0.09 x 0.37 m
Gross weight	0.866 kg
Net weight	0.615 kg
