Order no.: 0244170

MCX-200/SW

Order no.: 0244170

MCX-200/SW

Electronic stereo crossover network Subwoofer operation/satellite operationAdditional mono subwoofer outputOutput level can be adjusted individually for each frequency rangeSwitchable phase for subwoofer outputAdjustable crossover frequencyGround lift switchAll connections via 6.3 mm jacks, unbal.

continue

About

Electronic stereo crossover network

Subwoofer operation/satellite operation
Additional mono subwoofer output
Output level can be adjusted individually for each frequency range
Switchable phase for subwoofer output
Adjustable crossover frequency
Ground lift switch
All connections via 6.3 mm jacks, unbal.

Specifications

Frequency range	10-30,000 Hz, -0.5 dB
Crossover frequency	60-500 Hz, 12 dB/oct.
High-pass filter	15 Hz, 12 dB/oct.
THD	< 0.03%
Inputs	6 V max./56 kΩ
Outputs	6 V max./100 Ω (±10 dB)
S/N ratio	> 80 dB
Power supply	˜ 230 V/50 Hz/5 VA
Admiss. ambient temp.	0-40 °C
Dimensions	482 x 44.5 x 185 mm, 1 RS
Weight	2 kg
