Piezo tweeter
Manufacturer information:
MONACOR INTERNATIONAL GmbH & Co. KG
Zum Falsch 36
28307 Bremen
Germany
info@monacor.com
Zum Falsch 36
28307 Bremen
Germany
info@monacor.com
Specifications
| Impedance (Z) | > 1,000 Ω |
| Transmission technology | cable |
| Frequency range | 4,000-20,000 Hz |
| Power rating (RMS) | 60 W |
| Peak music power output (MAX) |
115 W (8 Ω system) 225 W (4 Ω system) |
| SPL | 94 dB/W/m |
| Max. voltage | ~ 30 V |
| Mounting cutout | Ø 77 mm |
| Mounting depth | 60 mm |
| Hole spacing X-axis | 70 mm |
| Hole spacing Y-axis | 70 mm |
| Dimensions | 85 x 85 x 72 mm |
| Width | 85 mm |
| Height | 85 mm |
| Depth | 72 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 0.059 kg |
| Packing unit | 1 |
| Packaging dimensions (W x H x L) | 0.085 x 0.075 x 0.085 m |
| Gross weight | 0.061 kg |
| Net weight | 0.059 kg |
| EAN code | 4007754181180 |
| Net weight | 0.059 kg |
