Order no.: 0348380

NAC-3FCHC

P_NEUTRIK

Order no.: 0348380

NAC-3FCHC

NEUTRIK POWERCON plug

For mains connection with a high power rating of up to ˜ 250 V/32 A
Screw terminal contacts for ground, phase and neutral conductor
For cable cores: 2.5-6 mm²
Robust version with latching device and cable inlet with self-adjusting clamps

Manufacturer information:

Neutrik AG
Im alten Ried 143
9494 Schaan
Liechtenstein
neutrik@neutrikgroup.com

continue

About

NEUTRIK POWERCON plug

For mains connection with a high power rating of up to ˜ 250 V/32 A
Screw terminal contacts for ground, phase and neutral conductor
For cable cores: 2.5-6 mm²
Robust version with latching device and cable inlet with self-adjusting clamps

Manufacturer information:

Neutrik AG
Im alten Ried 143
9494 Schaan
Liechtenstein
neutrik@neutrikgroup.com

Specifications

Description	plug
Type	NEUTRIK POWERCON
Quantity	1
Features	latching device
Colour/colour coding	black
Power rating	˜ 250 V/32 A
Insulating resistance	> 10 GΩ
Dielectric strength	DC 4 kV/˜ 2.8 kV
Certification	VDE, UL, cUL and JET
Pole number	2+PE
Cable inlet	8-20 mm
Connection	screw contacts
Strain relief	yes
Material	silver-plated bronze contacts, plastic
Weight	72 g

EAN code	7613187002281
Net weight	0.072 kg
