Order no.: 0259009

WAVE-10A

Order no.: 0259009

WAVE-10A

Pure Entertainment! The PA speaker systems of the WAVE series impress with a great sound and an attractive price. They are suitable for smaller to medium-sized function rooms and are the perfect starting equipment for entry-level DJs. The plastic cabinets of contemporary design are also lightweight and easy to use. Thus, they are ideally suited for mobile applications. Active full range speaker system, 300 W Compact 10/2 full range bass-reflex system with plastic cabinet 25 cm (10") bass speaker and 25 mm (1") horn tweeter Integrated MP3 player with USB/SD slot Bluetooth receiver Infrared remote control Balanced mic input via XLR jack or 6.3 mm jack Line input via RCA jack or XLR jack 2-way tone control for treble and bass Mix out via XLR or 6.3 mm jack M8 threaded inserts for mounting support Stand sleeve

continue

About

Pure Entertainment!

The PA speaker systems of the WAVE series impress with a great sound and an attractive price. They are suitable for smaller to medium-sized function rooms and are the perfect starting equipment for entry-level DJs. The plastic cabinets of contemporary design are also lightweight and easy to use. Thus, they are ideally suited for mobile applications.

Active full range speaker system, 300 W

Compact 10/2 full range bass-reflex system with plastic cabinet
25 cm (10") bass speaker and 25 mm (1") horn tweeter
Integrated MP3 player with USB/SD slot
Bluetooth receiver
Infrared remote control
Balanced mic input via XLR jack or 6.3 mm jack
Line input via RCA jack or XLR jack
2-way tone control for treble and bass
Mix out via XLR or 6.3 mm jack
M8 threaded inserts for mounting support
Stand sleeve

Specifications

Active/passive	active
Transmission technology	wireless/cable
Total output power	300 W
Power rating (RMS)	150 W
Frequency range	60-20,000 Hz
Input signal	250 mV/7 kΩ (line, XLR, bal.), 150 mV/16 kΩ (line, RCA), 9.5 mV/0.8 kΩ (mic, XLR, bal.), 9.5 mV/0.8 kΩ (mic, 6.3 mm jack)
System	10/2 full range bass-reflex
Bass speaker	25 cm (10") bass speaker
Tweeter	25 mm (1") horn tweeter
Number of speakers	2
Speaker size	25 cm (10")
SPL	95 dB/W/m
Max. rated SPL	119 dB
Radiation angle/beam angle	H: 90°/V: 60°
Radiation angle, horizontal	90°
Radiation angle, vertical	60°
Housing material	plastic
Colour	black
Mounting device	M8 threaded inserts, stand sleeve
Admiss. ambient temp.	0-40 °C
Power supply	˜ 230 V/50 Hz/270 VA
Dimensions	300 x 510 x 250 mm
Width	300 mm
Height	510 mm
Depth	250 mm
Weight	9.4 kg
Inputs	XLR or RCA L/R (line) XLR or 6.3 mm jack (mic)
Outputs	XLR, bal. (parallel line out)
Packing dimensions (W x H x L)	0.35 x 0.56 x 0.315 m
Gross weight	10.27 kg
Net weight	9.38 kg
